Physical quantities and units

CIE 9702 PhysicsASFree revision notes

Contents: 6 sections

Cambridge International AS & A Level Physics 9702 · AS

This topic is the grammar of the whole course. Nothing in it is hard, but every later topic assumes it: a wrong unit, a dropped prefix or a vector added as if it were a scalar costs marks in mechanics, electricity and nuclear physics alike. There are four subtopics: what a physical quantity is and how to estimate one, SI units, errors and uncertainties, and scalars and vectors.

1.1 Physical quantities

Magnitude and unit

Every physical quantity has two parts: a numerical magnitude and a unit. "The length is 2.5" says nothing. "The length is 2.5 m" is a measurement.

The unit is not decoration. 2.5 m and 2.5 mm differ by a factor of a thousand, and an answer written without a unit, or with the wrong one, loses the mark even when the number is right. Treat the unit as part of the value: carry it through every line of working, and it will often tell you when you have used the wrong equation.

Making reasonable estimates

Cambridge expects you to estimate the size of quantities that appear in the syllabus, usually to the nearest power of ten. Multiple-choice questions ask which value is closest to, say, the mass of an adult or the power of a kettle, and structured questions sometimes ask you to estimate a quantity before calculating with it.

The method is always the same: start from values you know about everyday objects, round them to one significant figure, and combine them. The answer only has to be the right order of magnitude.

These are the values worth carrying in your head:

QuantityTypical value
Mass of an adult70 kg
Mass of an apple0.1 kg
Mass of a car1000 kg to 1500 kg
Height of an adult1.7 m
Diameter of an atom10⁻¹⁰ m
Diameter of a nucleus10⁻¹⁵ m
Wavelength of visible light400 nm to 700 nm
Walking speed1.5 m s⁻¹
Speed of a car on a motorway30 m s⁻¹
Speed of sound in air330 m s⁻¹
Speed of light3.00 × 10⁸ m s⁻¹
Density of air1.2 kg m⁻³
Density of water1000 kg m⁻³
Atmospheric pressure1.0 × 10⁵ Pa
Power of a filament lamp60 W
Power of a kettle2 kW
Mains voltage230 V
Current in a lamp0.25 A
Weight of an apple1 N

Worked example. Estimate the kinetic energy of a sprinter running at full speed.

Mass of a sprinter ≈ 70 kg. A 100 m race takes about 10 s, so top speed ≈ 10 m s⁻¹.

E_K = ½mv² ≈ ½ × 70 kg × (10 m s⁻¹)² = 3500 J

So the kinetic energy is about 3 × 10³ J. Any answer between about 2000 J and 5000 J is a reasonable estimate. An answer of 35 J or 350 000 J shows a slip in the mass or the speed, and that is exactly what the question is testing.

Worked example. Estimate the pressure a standing adult exerts on the floor.

Weight ≈ 70 kg × 9.81 m s⁻² ≈ 700 N. Each shoe sole is roughly 0.25 m by 0.08 m, so the area of two soles ≈ 2 × 0.02 m² = 0.04 m².

p = F / A ≈ 700 N / 0.04 m² = 17 500 Pa

So the pressure is about 2 × 10⁴ Pa. The trap is estimating the area in cm² and dividing by it without converting: 700 / 400 gives about 2 Pa, which is a factor of 10⁴ too small.

1.2 SI units

The base quantities

The SI system builds every unit from a small set of base quantities. Five of them are needed at AS Level:

Base quantityBase unitSymbol
Masskilogramkg
Lengthmetrem
Timeseconds
Electric currentampereA
Thermodynamic temperaturekelvinK

A sixth, amount of substance with the unit mol, is added in topic 15 at A Level.

Two details are examined often. The base unit of mass is the kilogram, not the gram, and it is the only base unit that already carries a prefix. And the base unit of temperature is the kelvin, written K with no degree sign. Charge is not a base quantity: current is, and the coulomb is derived from it.

Derived units

Every other unit is a derived unit, a product or quotient of base units. You find it by writing down an equation that defines the quantity and substituting the base units of everything in it. Work in symbols and simplify at the end; trying to remember the answer is how people write kg m s⁻² for pressure.

QuantityDefining equationDerived unitIn base units
Velocityv = Δs / Δtm s⁻¹m s⁻¹
Accelerationa = Δv / Δtm s⁻²m s⁻²
ForceF = manewton, Nkg m s⁻²
Work and energyW = Fsjoule, Jkg m² s⁻²
PowerP = W / twatt, Wkg m² s⁻³
Pressure and stressp = F / Apascal, Pakg m⁻¹ s⁻²
ChargeQ = Itcoulomb, CA s
Potential differenceV = W / Qvolt, Vkg m² s⁻³ A⁻¹
ResistanceR = V / Iohm, Ωkg m² s⁻³ A⁻²
Frequencyf = 1 / Thertz, Hzs⁻¹

Worked example. Express the unit of the Young modulus in SI base units.

Young modulus = stress / strain. Strain is a ratio of two lengths, so it has no unit, and the Young modulus has the unit of stress.

Stress = force / area, so its unit is N m⁻².

N = kg m s⁻², so N m⁻² = kg m s⁻² × m⁻² = kg m⁻¹ s⁻².

Worked example. The drag force on a car is modelled as F = kv², where v is the speed. Find the base units of k.

k = F / v², so its unit is (kg m s⁻²) / (m s⁻¹)² = kg m s⁻² / (m² s⁻²) = kg m⁻¹.

The trap is squaring the number part of the unit and forgetting to square the s⁻¹. Write the bracket out in full before you cancel.

Checking homogeneity

An equation is homogeneous when every term in it has the same base units. A physically correct equation must be homogeneous, so checking the base units is a quick way to catch a misremembered formula.

Worked example. Show that s = ut + ½at² is homogeneous.

Every term is in metres, so the equation is homogeneous.

Worked example. A student writes v = u + as. Is this homogeneous?

v and u are in m s⁻¹. The term as has the unit m s⁻² × m = m² s⁻², which is not m s⁻¹. The equation is not homogeneous, so it cannot be correct. (The correct equation is v = u + at.)

Homogeneity is a necessary condition, not a sufficient one. An equation can be homogeneous and still wrong, because pure numbers such as ½, 2 or π have no unit and a missing one is invisible to the check. E_K = mv² is homogeneous but wrong. So homogeneity shows that an equation could be correct, never that it is.

Prefixes

PrefixSymbolFactor
picop10⁻¹²
nanon10⁻⁹
microμ10⁻⁶
millim10⁻³
centic10⁻²
decid10⁻¹
kilok10³
megaM10⁶
gigaG10⁹
teraT10¹²

The case of the letter matters: M is mega and m is milli, a factor of 10⁹ apart.

A prefix on a squared or cubed unit is squared or cubed with it, because the prefix belongs to the unit inside the bracket:

Worked example. A wire has a cross-sectional area of 0.20 mm². Express this in m².

0.20 mm² = 0.20 × (10⁻³ m)² = 0.20 × 10⁻⁶ m² = 2.0 × 10⁻⁷ m².

Writing 0.20 × 10⁻³ m² is the standard error, and it makes every stress calculation that follows wrong by a factor of a thousand.

Worked example. A dm³ is a common unit of volume. How many dm³ are there in 1 m³?

1 dm³ = (10⁻¹ m)³ = 10⁻³ m³, so 1 m³ = 1000 dm³. One dm³ is one litre.

1.3 Errors and uncertainties

No measurement is exact. The uncertainty in a measurement is the range within which the true value is expected to lie, written as a value, an uncertainty and a unit: 24.6 ± 0.2 cm.

Random errors

A random error makes repeated readings scatter unpredictably either side of the true value. Causes include judging a reading by eye, reaction time when starting and stopping a stop-watch, and small fluctuations in the conditions.

Random errors can be reduced by taking repeated readings and averaging them, and by plotting a graph and drawing a line of best fit, which averages over many points. They can never be removed completely.

Systematic errors

A systematic error shifts every reading by the same amount, or in the same proportion, in the same direction. Causes include:

Repeating readings does not reduce a systematic error, because the same error is added to every reading and the average carries it too. It is removed by correcting the readings, recalibrating the instrument or changing the method.

On a graph a systematic zero error shifts every point by the same amount, so the line keeps its gradient but its intercept moves. That is why many experiments find a constant from the gradient rather than from a single reading: the gradient is unaffected by a zero error.

Worked example. A micrometer reads +0.03 mm when its jaws are closed with nothing between them. It then reads 2.47 mm across a wire. What is the diameter?

The instrument adds 0.03 mm to every reading, so the true diameter is 2.47 − 0.03 = 2.44 mm.

Adding the 0.03 mm instead of subtracting it is the error to avoid. Ask yourself whether the instrument reads high or low, then correct in the opposite direction.

Precision and accuracy

These two words are not interchangeable, and questions set them against each other on purpose.

Readings can be precise but inaccurate, which is exactly what a zero error produces: tightly grouped readings, all offset by the same amount. Readings can also be accurate on average but imprecise, when they scatter widely around the true value.

Worked example. A desk is known to be 50.0 cm wide. A student records 48.01, 47.99, 48.01, 48.00 and 47.99 cm.

The readings agree to within 0.02 cm, so they are precise. Their mean is 48.00 cm, which is 2.00 cm from the true value, so they are not accurate. A systematic error, such as using a ruler with a damaged end, is the likely cause. The presence of a true value in the question is the signal that accuracy is being tested.

Absolute, fractional and percentage uncertainty

For a length of 24.6 ± 0.2 cm, the percentage uncertainty is 0.2 / 24.6 × 100 = 0.81%.

For repeated readings, the absolute uncertainty can be taken as half the range. Readings of 2.31 s, 2.27 s and 2.35 s have a mean of 2.31 s and a range of 0.08 s, so the result is 2.31 ± 0.04 s.

Combining uncertainties

When a quantity is calculated from measured values, its uncertainty is found from theirs by three rules.

Uncertainties are always added, never subtracted, even when the quantities themselves are subtracted or divided.

Worked example. A cube has sides of 2.0 ± 0.1 cm. What is the percentage uncertainty in its volume?

Percentage uncertainty in the side = 0.1 / 2.0 × 100 = 5%.

Volume = side³, so the percentage uncertainty in the volume is 3 × 5 = 15%.

Worked example. A metal cylinder has mass m = 50.0 ± 0.1 g, diameter d = 2.00 ± 0.02 cm and length L = 5.00 ± 0.05 cm. Find its density with its absolute uncertainty.

Volume V = π(d/2)²L = π × (1.00 cm)² × 5.00 cm = 15.7 cm³.

ρ = m / V = 50.0 g / 15.7 cm³ = 3.18 g cm⁻³ = 3180 kg m⁻³.

Since ρ = 4m / (πd²L), the percentage uncertainties are:

Total = 0.2 + 2 + 1 = 3.2%. The absolute uncertainty is 3.2% of 3180 kg m⁻³ ≈ 100 kg m⁻³.

So ρ = (3.2 ± 0.1) × 10³ kg m⁻³. The uncertainty is given to one significant figure and the value is rounded to the same decimal place. The factor π is exact and contributes nothing.

Worked example. Two lengths are measured as 50.0 ± 0.5 mm and 48.0 ± 0.5 mm. What is their difference and its percentage uncertainty?

Difference = 50.0 − 48.0 = 2.0 mm. The absolute uncertainties add: 0.5 + 0.5 = 1.0 mm.

So the difference is 2.0 ± 1.0 mm, a percentage uncertainty of 50%, from two readings that were each uncertain by only 1%. Subtracting two similar values destroys precision, and questions use this to ask why one method of measurement is better than another.

1.4 Scalars and vectors

The difference

A scalar has magnitude only. A vector has magnitude and direction.

ScalarsVectors
Distance, speedDisplacement, velocity
Mass, timeAcceleration, force, weight
Energy, work, powerMomentum
Temperature, density, pressureElectric field strength
Charge, potential differenceGravitational field strength

Pairs that are asked directly: weight is a vector and mass is a scalar; velocity is a vector and speed is a scalar; pressure is a scalar even though the force producing it is a vector. Work and energy are scalars although they are calculated from two vectors.

Adding vectors

Vectors are added tip to tail. Draw the first vector, draw the second starting from the tip of the first, and the resultant runs from the start of the first to the tip of the second. The order does not matter.

For two vectors at right angles, use Pythagoras for the size and tan for the direction. For any other angle, draw a scale diagram, or use the cosine and sine rules on the triangle.

A vector triangle adding two forces. A force of 8.0 N acts to the right and a force of 5.0 N acts at 60 degrees to it. Drawn tip to tail, they form a triangle whose third side is the resultant, 11 N at 22 degrees to the 8.0 N force. The angle inside the triangle between the two forces is 120 degrees.
A vector triangle adding two forces. A force of 8.0 N acts to the right and a force of 5.0 N acts at 60 degrees to it. Drawn tip to tail, they form a triangle whose third side is the resultant, 11 N at 22 degrees to the 8.0 N force. The angle inside the triangle between the two forces is 120 degrees.

Worked example. Two forces of 8.0 N and 5.0 N act at a point, with an angle of 60° between them. Find the resultant.

Drawn tip to tail, the angle inside the triangle between the two forces is 180° − 60° = 120°.

Cosine rule: R² = 8.0² + 5.0² − 2 × 8.0 × 5.0 × cos 120° = 64 + 25 + 40 = 129, so R = 11.4 N.

Sine rule for the direction, with α the angle between R and the 8.0 N force: sin α = 5.0 × sin 120° / 11.4 = 0.381, so α = 22°.

The resultant is 11 N at 22° to the 8.0 N force. The trap is putting 60° into the cosine rule. That gives R = 7.0 N, smaller than either force would suggest for two forces pulling roughly the same way.

The resultant of two vectors of sizes a and b always lies between a − b and a + b (taking a as the larger). Two forces of 8.0 N and 5.0 N can give any resultant from 3.0 N to 13.0 N and nothing outside it. That bracket alone answers several multiple-choice questions.

Subtracting vectors

To subtract a vector, add its negative: A − B = A + (−B), where −B has the same size as B and the opposite direction.

This is how a change in a vector quantity is found. The change in velocity is Δv = v − u, the final velocity minus the initial, and it is a vector subtraction whenever the direction changes.

Worked example. A ball moving east at 4.0 m s⁻¹ is deflected and moves north at 3.0 m s⁻¹. Find the change in velocity.

Δv = v − u = (3.0 m s⁻¹ north) + (4.0 m s⁻¹ west).

The two parts are at right angles, so |Δv| = √(3.0² + 4.0²) = 5.0 m s⁻¹, and tan θ = 4.0 / 3.0 gives θ = 53°.

The change in velocity is 5.0 m s⁻¹ at 53° west of north. The speed changed by only 1.0 m s⁻¹, but the velocity changed by 5.0 m s⁻¹. Subtracting the speeds instead of the vectors is the standard mistake.

Resolving a vector into components

Any vector can be replaced by two perpendicular components that together have the same effect. A force F at an angle θ to the horizontal has:

The component next to the angle takes the cosine. If the angle is measured from the vertical instead, the two swap, so always read the angle off the diagram rather than assuming where it is.

A force of 50 N pulling at 30 degrees above the horizontal, resolved into perpendicular components. The horizontal component, 50 cos 30 degrees, is 43 N. The vertical component, 50 sin 30 degrees, is 25 N. Dashed lines complete the rectangle with the 50 N force as its diagonal.
A force of 50 N pulling at 30 degrees above the horizontal, resolved into perpendicular components. The horizontal component, 50 cos 30 degrees, is 43 N. The vertical component, 50 sin 30 degrees, is 25 N. Dashed lines complete the rectangle with the 50 N force as its diagonal.

Worked example. A rope pulls a sledge with a force of 50 N at 30° above the horizontal. Find the components.

Horizontal: 50 × cos 30° = 43.3 N, so 43 N.

Vertical: 50 × sin 30° = 25 N.

Check: √(43.3² + 25²) = 50 N, so the components rebuild the original force.

Worked example. A block of mass 2.0 kg rests on a slope inclined at 25° to the horizontal. Find the components of its weight along and perpendicular to the slope.

W = mg = 2.0 × 9.81 = 19.6 N.

Along the slope: W sin 25° = 19.6 × 0.423 = 8.3 N, down the slope.

Perpendicular to the slope: W cos 25° = 19.6 × 0.906 = 17.8 N, into the slope.

On a slope the angle between the weight and the perpendicular to the slope equals the angle of the slope, so the component along the slope takes the sine. Students who apply "horizontal takes cosine" here get the two answers the wrong way round. Check with a limiting case: on a flat surface (0°) nothing should act along the slope, and sin 0° = 0 confirms it.

Common mistakes

Check you have it

Question 1

Which row shows a physical quantity and its base unit in the SI system? Each answer gives, in order: quantity; unit.

Table from the Cambridge Physics 9702 Paper 1 February/March 2024 paper, variant 2, question 1.

Question 2

A copper pipe has a true diameter of 42.03 mm.
A builder measures the diameter of the pipe five times using digital calipers. The measurements are shown.
diameter / mm
48.01
47.99
48.01
48.00
47.99
What describes the builder’s measurements?

Table from the Cambridge Physics 9702 Paper 1 May/June 2023 paper, variant 1, question 3.

Question 3

A hollow cylinder, which is open at both ends, has a radius of (3.0 ± 0.1) cm and a length of (15.0 ± 0.1) cm.
What is the value, with its absolute uncertainty, of the surface area of the cylinder?

What the syllabus asks for on this topicSyllabus points

Syllabus points

1.1 Physical quantities

  • Understand that every physical quantity consists of a numerical magnitude and a unit.
  • Make reasonable estimates of physical quantities included in the syllabus.

1.2 SI units

  • Recall the SI base quantities and their units: mass (kg), length (m), time (s), current (A) and temperature (K).
  • Express derived units as products or quotients of the SI base units, and use derived units for the quantities in the syllabus.
  • Use SI base units to check the homogeneity of physical equations.
  • Recall and use the prefixes pico (p), nano (n), micro (μ), milli (m), centi (c), deci (d), kilo (k), mega (M), giga (G) and tera (T).

1.3 Errors and uncertainties

  • Understand and explain the effects of systematic errors, including zero errors, and random errors in measurements.
  • Understand the distinction between precision and accuracy.
  • Assess the uncertainty in a derived quantity by simple addition of absolute or percentage uncertainties.

1.4 Scalars and vectors

  • Understand the difference between scalar and vector quantities, and give examples of each from the syllabus.
  • Add and subtract coplanar vectors.
  • Represent a vector as two perpendicular components.
