11.1 Atoms, nuclei and radiation

The α-particle scattering experiment

In the experiment, a narrow beam of α-particles from a radioactive source is directed at a very thin gold foil, all inside an evacuated chamber so that the α-particles are not stopped or scattered by air. A detector (originally a zinc sulfide screen viewed through a microscope, which gives a tiny flash for each α-particle) is moved round the foil to count how many α-particles arrive per minute at each angle of deflection.

Computed paths of α-particles approaching a gold nucleus along parallel lines. Those passing far from the nucleus are deflected by about 10° and 22°, one passing close is deflected by about 78°, and one heading almost straight at it is turned back through about 150°. The nucleus is about 10⁻¹⁴ m across and the atom about 10⁻¹⁰ m, so the diagram is not to scale.
Computed paths of α-particles approaching a gold nucleus along parallel lines. Those passing far from the nucleus are deflected by about 10° and 22°, one passing close is deflected by about 78°, and one heading almost straight at it is turned back through about 150°. The nucleus is about 10⁻¹⁴ m across and the atom about 10⁻¹⁰ m, so the diagram is not to scale.

The observations, and what each one lets you infer:

ObservationInference
Almost all the α-particles pass straight through the foil or are deflected by only a few degreesMost of the atom is empty space: most α-particles never come close to anything that can deflect them
A small fraction are deflected through large anglesThere is a concentrated region of positive charge that repels the positive α-particles strongly when they pass close to it
A very small fraction (of order one in many thousands) are deflected by more than 90°, back towards the sourceThat region contains most of the mass of the atom, so it is not pushed aside by the heavy α-particle, and it is very small, which is why so few α-particles come close enough to be turned back

From these results it is inferred that the atom has a nucleus: tiny (about 10⁻¹⁴ m across, compared with about 10⁻¹⁰ m for the atom), positively charged, and containing almost all of the atom's mass.

The inference about size comes from the rarity of the large deflections, not from the large deflections themselves. The large deflections show that the charge and mass are concentrated; the fact that so few α-particles are affected shows that the concentration is tiny.

A simple model of the nuclear atom

Proton number, nucleon number and nuclide notation

A particular nucleus is a nuclide. It is written with the nucleon number A at the top left of the chemical symbol X and the proton number Z at the bottom left. For example:

²³⁵₉₂U

is uranium-235, which has 92 protons, 235 nucleons and 235 − 92 = 143 neutrons.

Isotopes

Isotopes are forms of the same element whose nuclei have the same number of protons but different numbers of neutrons: same Z, different A. Hydrogen ¹₁H and deuterium ²₁H are isotopes: both have one proton, but deuterium also has one neutron. Isotopes of an element have the same chemical properties, because chemistry depends on the electrons, but different masses and often different nuclear stability.

Conservation in nuclear processes

In every nuclear process, nucleon number and charge are conserved. In a nuclear equation, that means the top numbers (A) balance and the bottom numbers (Z, which give the charge in units of e) balance. This one rule answers most decay-equation questions.

α-, β- and γ-radiation

αβ⁻β⁺γ
What it isHelium nucleus: 2 protons + 2 neutronsElectron, emitted from a nucleusPositron, emitted from a nucleusElectromagnetic radiation (a photon)
MassAbout 4 uAbout 5.5 × 10⁻⁴ u (roughly 1/1820 u)The same as β⁻Zero (no rest mass)
Charge+2e−e+e0
Notation⁴₂α or ⁴₂He⁰₋₁β or ⁰₋₁e⁰₊₁β or ⁰₊₁eγ

Both kinds of β-particle are created in the nucleus at the moment of decay: they are not electrons that were already there.

Because charge and mass differ so much, so does the specific charge (charge/mass). This is examined directly.

Worked example 1. Find the specific charge of an α-particle, a proton and a β⁻ particle, and put them in order. Use 1 u = 1.66 × 10⁻²⁷ kg, m_p = 1.67 × 10⁻²⁷ kg and m_e = 9.11 × 10⁻³¹ kg.

Mass of α-particle ≈ 4.00 u = 4.00 × 1.66 × 10⁻²⁷ = 6.64 × 10⁻²⁷ kg.

α: 2 × 1.60 × 10⁻¹⁹ / (6.64 × 10⁻²⁷) = 4.82 × 10⁷, so 4.8 × 10⁷ C kg⁻¹.

Proton: 1.60 × 10⁻¹⁹ / (1.67 × 10⁻²⁷) = 9.58 × 10⁷, so 9.6 × 10⁷ C kg⁻¹.

β⁻: 1.60 × 10⁻¹⁹ / (9.11 × 10⁻³¹) = 1.76 × 10¹¹, so 1.8 × 10¹¹ C kg⁻¹.

In increasing order: α, proton, β. The α-particle has twice the proton's charge but four times its mass, so half its specific charge. The trap is ranking by charge alone and putting α last.

Antiparticles

Every particle has an antiparticle with the same mass but the opposite charge. The positron (the β⁺ particle) is the antiparticle of the electron: same mass, charge +e instead of −e.

Neutrinos and antineutrinos

β-decay always produces a third particle besides the new nucleus and the β-particle:

Neutrinos and antineutrinos have no charge and an extremely small mass, and they interact so weakly with matter that they almost always pass through undetected.

Why α energies are discrete and β energies are continuous

Left: all the α-particles from one nuclide have the same kinetic energy, a single line at 4.8 MeV. Right: β⁻ particles from one nuclide have a continuous range of kinetic energies from zero up to a maximum of 1.0 MeV; a β-particle emitted with 0.3 MeV shares the energy with an antineutrino that carries the other 0.7 MeV.
Left: all the α-particles from one nuclide have the same kinetic energy, a single line at 4.8 MeV. Right: β⁻ particles from one nuclide have a continuous range of kinetic energies from zero up to a maximum of 1.0 MeV; a β-particle emitted with 0.3 MeV shares the energy with an antineutrino that carries the other 0.7 MeV.

Each decay of a given nuclide releases the same total energy.

This continuous spectrum is the evidence that led to the neutrino being proposed: without a third particle, β-particles with less than the maximum energy would break conservation of energy.

Decay equations

The general forms, with X the parent nucleus, Y the daughter, and X(A, Z) meaning nucleon number A and proton number Z:

Cambridge's own model is the decay of uranium-238 to thorium-234:

²³⁸₉₂U → ²³⁴₉₀Th + ⁴₂α

Check: top 238 = 234 + 4; bottom 92 = 90 + 2.

Worked example 2. Carbon-14 (Z = 6) decays by β⁻ emission. Write the equation.

Z rises by 1 to 7, which is nitrogen, and A stays 14:

¹⁴₆C → ¹⁴₇N + ⁰₋₁β + ν̄

Check: top 14 = 14 + 0; bottom 6 = 7 + (−1). The antineutrino has A = 0 and Z = 0. The trap is decreasing Z because a negative particle has left. Follow the bookkeeping: losing −1 of charge leaves the nucleus 1 more positive.

Worked example 3. Sodium-22 (Z = 11) decays by β⁺ emission. Write the equation and name the other particle emitted.

²²₁₁Na → ²²₁₀Ne + ⁰₊₁β + ν

The other particle is an (electron) neutrino, not an antineutrino. Check: 22 = 22 + 0 and 11 = 10 + 1.

Worked example 4. Uranium-238 (Z = 92) emits an α-particle and then two β⁻ particles. Find the nucleon and proton numbers of the final nuclide.

After the α-decay: A = 238 − 4 = 234 and Z = 92 − 2 = 90.

After two β⁻ decays: A stays 234 and Z = 90 + 2 = 92.

The final nuclide is ²³⁴₉₂U: A = 234, Z = 92, an isotope of the original element.

The unified atomic mass unit

The unified atomic mass unit (u) is a convenient unit for the masses of atoms, nuclei and particles. Its value is on the data sheet:

1 u = 1.66 × 10⁻²⁷ kg

A proton and a neutron each have a mass of about 1 u, so the mass of a nucleus in u is roughly its nucleon number.

Worked example 5. Estimate the mass of a uranium-238 nucleus in kilograms, and express the electron's mass in u.

Uranium-238: mass ≈ 238 u = 238 × 1.66 × 10⁻²⁷ = 3.95 × 10⁻²⁵ kg, so about 3.95 × 10⁻²⁵ kg.

Electron: 9.11 × 10⁻³¹ / (1.66 × 10⁻²⁷) = 5.49 × 10⁻⁴, so m_e = 5.49 × 10⁻⁴ u, about 1/1820 of a unit.

The trap is multiplying when converting kg to u. To go from kilograms to u, divide by 1.66 × 10⁻²⁷.

11.2 Fundamental particles

Quarks

A fundamental particle is one with no internal structure: it is not made of anything smaller. Quarks are fundamental particles, and there are six flavours (types): up, down, strange, charm, top and bottom.

QuarkSymbolCharge
upu+⅔e
downd−⅓e
stranges−⅓e
charmc+⅔e
topt+⅔e
bottomb−⅓e

A pattern to remember: up, charm and top are +⅔e; down, strange and bottom are −⅓e.

Each quark has an antiquark with the opposite charge, written with a bar: the anti-up quark ū has charge −⅔e and the anti-down quark d̄ has +⅓e. Cambridge examines only the charges of quarks, nothing else about them.

Protons and neutrons are not fundamental

Protons and neutrons are made of quarks:

Being able to rebuild both charges from the quark table, rather than relying on memory, is what makes unfamiliar combinations answerable.

Hadrons: baryons and mesons

Particles made of quarks are called hadrons. There are two kinds:

The charge of a hadron is the sum of the charges of its quarks, and it must come out as a whole number of e.

Worked example 6. Find the charges of a baryon with quarks uds, a meson made of u and d̄, and a meson made of s and ū.

uds: +⅔ − ⅓ − ⅓ = 0, so charge 0.

u d̄: +⅔ + ⅓ = +1, so charge +e. (The anti-down quark has +⅓e.)

s ū: −⅓ − ⅔ = −1, so charge −e.

The trap is forgetting that the antiquark's charge is reversed, which gives u d̄ a charge of +⅓e, a value no hadron can have.

Worked example 7. A particle consists of a charm quark and an anti-strange quark. Is it a baryon or a meson, and what is its charge?

One quark and one antiquark: a meson. Charge = +⅔ + ⅓ = +1 (in units of e), since the anti-strange quark has +⅓e.

β-decay in terms of quarks

In β⁻ decay, a neutron becomes a proton. In quark terms, a down quark changes into an up quark:

udd → uud, that is, d → u + e⁻ + ν̄

In β⁺ decay, a proton becomes a neutron: an up quark changes into a down quark:

uud → udd, that is, u → d + e⁺ + ν

β⁻ decay: a neutron, udd with charge 0, becomes a proton, uud with charge +1, when one down quark (−⅓e) changes to an up quark (+⅔e), emitting an electron and an electron antineutrino. β⁺ decay: a proton becomes a neutron when one up quark changes to a down quark, emitting a positron and an electron neutrino.
β⁻ decay: a neutron, udd with charge 0, becomes a proton, uud with charge +1, when one down quark (−⅓e) changes to an up quark (+⅔e), emitting an electron and an electron antineutrino. β⁺ decay: a proton becomes a neutron when one up quark changes to a down quark, emitting a positron and an electron neutrino.

Charge is conserved at the quark level too. For β⁻: on the left −⅓; on the right +⅔ − 1 + 0 = −⅓. For β⁺: on the left +⅔; on the right −⅓ + 1 + 0 = +⅔.

The other two quarks are unchanged in both decays. A question that asks for "the change in quark composition" wants exactly one quark changing: down to up for β⁻, up to down for β⁺.

Leptons

Electrons and neutrinos are fundamental particles called leptons. Unlike hadrons, they are not made of quarks. The positron and the antineutrino are antileptons, and they are fundamental too.

So among the particles in this topic: quarks, electrons, positrons, neutrinos and antineutrinos are fundamental; protons, neutrons and mesons are not, because they are made of quarks; and an α-particle is not fundamental either, being made of four nucleons.

Common mistakes

Check you have it

Question 1

A π+ meson has a charge of +e, where e is the elementary charge. It consists of an up quark and one other quark.
What could be the other quark in the π+ meson?

Question 2

A top quark has a charge of + ² e , where e is the elementary charge. 3
What is the charge of an anti top quark?

Table from the Cambridge Physics 9702 Paper 1 February/March 2023 paper, variant 2, question 40.

Question 3

Some particles are a combination of three quarks.
Which combination of quarks does not result in a particle with a charge of either +1.6 × 10⁻¹⁹ C or zero?

What the syllabus asks for on this topicSyllabus points

Syllabus points

11.1 Atoms, nuclei and radiation

  • Infer the existence and small size of the nucleus from the results of the α-particle scattering experiment.
  • Describe a simple model of the nuclear atom with protons, neutrons and orbital electrons.
  • Distinguish between nucleon number and proton number.
  • Understand that isotopes are forms of the same element with different numbers of neutrons in their nuclei.
  • Understand and use nuclide notation, with the nucleon number A written above the proton number Z to the left of the symbol, as in ²³⁵₉₂U.
  • Understand that nucleon number and charge are conserved in nuclear processes.
  • Describe the composition, mass and charge of α-, β- and γ-radiations, including both β⁻ (electrons) and β⁺ (positrons).
  • Understand that an antiparticle has the same mass but opposite charge to its particle, and that the positron is the antiparticle of the electron.
  • State that (electron) antineutrinos are produced in β⁻ decay and (electron) neutrinos in β⁺ decay.
  • Understand that α-particles have discrete energies but β-particles have a continuous range of energies because (anti)neutrinos are emitted in β-decay.
  • Represent α- and β-decay by radioactive decay equations of the form ²³⁸₉₂U → ²³⁴₉₀Th + ⁴₂α.
  • Use the unified atomic mass unit (u) as a unit of mass.

11.2 Fundamental particles

  • Understand that a quark is a fundamental particle and that there are six flavours: up, down, strange, charm, top and bottom.
  • Recall and use the charge of each flavour of quark, and understand that its antiquark has the opposite charge.
  • Recall that protons and neutrons are not fundamental, and describe them in terms of their quark composition.
  • Understand that a hadron is either a baryon (three quarks) or a meson (one quark and one antiquark).
  • Describe the changes in quark composition in β⁻ and β⁺ decay.
  • Recall that electrons and neutrinos are fundamental particles called leptons.
